IoT DEVICES

FOR ANY JOB

All LegioBox devices are built from the same set of function blocks, sharing a common design base of tried-and-tested modules. Avic supplies IoT devices with the most widely used functions from stock, but can also rapidly create application-specific designs from its IoT device building block library.

Working out-of-the box, the tight integration of the LegioBox IoT devices with the Avision IoT Platform makes their operation and management as simple as possible. Generic functions such as device management, secure communication, data storage and processing have been put to the test in many solutions, giving you the peace of mind that your device will not fail on you. With Avic’s LegioBox devices, your IoT solution will work flawlessly, and deliver the results that you seek to achieve.

MIX-AND-MATCH

bouwstenen_full

Rugged, reliable, and energy-efficient

The Avic LegioBox IoT devices are designed for operation in harsh environments with ample protection against the roughest conditions, and minimal power consumption. Hooking up sensors has been made as simple as possible with standardized connectors.

Wide choice of functions

Whatever functionality your IoT solution demands, the LegioBox IoT devices will meet the requirements. Avic’s smart device design allows virtually any arrangement of functions.

Seamless integration with Avision

Perhaps the greatest advantage that LegioBox devices have to offer is the close integration with the Avision IoT Platform, letting you define the functional behavior without any programming. Out-of-the-box, a LegioBox device will work plug&play, and can be managed directly from your IoT solution to produce the value that needs to be delivered.

THE PERFECT FIT

FOR ANY SOLUTION

All LegioBox IoT devices share a common base of functional entities, to support a wide variety of applications.
The various function blocks are designed to be combined as needed. The most common configurations are supported by the standard LegioBox IoT devices, that can be altered for customized solutions. Taking it one step further, new function blocks can be integrated to create tailor-made IoT devices.

[ess_grid alias=”avic-1″ layers=”{‘custom-image’:{’00’:’1998′,’01’:’1999′,’02’:’2000′,’03’:’2001′,’04’:’2002′},’custom-type’:{’00’:’image’,’01’:’image’,’02’:’image’,’03’:’image’,’04’:’image’},’use-skin’:{’00’:’-1′,’01’:’-1′,’02’:’-1′,’03’:’-1′,’04’:’-1′}}”]

Avic Legiobox

PicoWise

Avic Legiobox

PicoWise

The LegioBox PicoWise is a small but powerful IoT device that is designed to operate as a node in wireless sensor network. The LegioBox PicoWise excels in applications that require high-resolution sensor measurements from many isolated locations, e.g. in food-chain temperature monitoring, or in greenhouse climate control. Different versions of the PicoWise can be combined to serve the specific needs of the IoT solution. Please contact Avic for more information on the benefits and features of the PicoWise wireless networking technology.

Various analog and digital sensors can be connected to the LegioBox PicoWise, that – thanks to the integrated sensor supply voltage generation – do not require additional power sources for performing measurements. The LegioBox PicoWise also provides digital inputs and integrated environmental sensors. For local user alerting, the PicoWise has a buzzer that creates an audible signal.

The LegioBox PicoWise is designed to work in any-weather outdoor applications, as well as indoor in situations where compliance with hygene standards must be guaranteed. Mounting accesories are available to ensure that the LegioBox PicoWise is securely installed during operation.

Product features

  • Pt-1000 temperature sensor interfaces
  • 4-20mA sensor intrerfaces
  • 0-10VDC sensor interfaces
  • Digital inputs
  • RS-232 data communication port
  • RS-485 data communication port
  • SDI-12 serial sensor interface
  • Relative humidity sensor (internal)
  • Barometer (internal)
  • Accelerometer

Sensors and interfaces

  • WISE RF communication
  • Internal antenna
  • UPS power supply backup (mains versions)
  • Internal thermometer
  • Ruggedized IP-67 enclosure
  • Sensor supply voltage generation
  • M8-style sensor connectors

MORE DETAILS

The LegioBox PicoWise is a small but powerful IoT device that is designed to operate as a node in wireless sensor network. The LegioBox PicoWise excels in applications that require high-resolution sensor measurements from many isolated locations, e.g. in food-chain temperature monitoring, or in greenhouse climate control. Different versions of the PicoWise can be combined to serve the specific needs of the IoT solution. Please contact Avic for more information on the benefits and features of the PicoWise wireless networking technology.

Various analog and digital sensors can be connected to the LegioBox PicoWise, that – thanks to the integrated sensor supply voltage generation – do not require additional power sources for performing measurements. The LegioBox PicoWise also provides digital inputs and integrated environmental sensors. For local user alerting, the PicoWise has a buzzer that creates an audible signal.

The LegioBox PicoWise is designed to work in any-weather outdoor applications, as well as indoor in situations where compliance with hygene standards must be guaranteed. Mounting accesories are available to ensure that the LegioBox PicoWise is securely installed during operation.

Product features

  • Pt-1000 temperature sensor interfaces
  • 4-20mA sensor intrerfaces
  • 0-10VDC sensor interfaces
  • Digital inputs
  • RS-232 data communication port
  • RS-485 data communication port
  • SDI-12 serial sensor interface
  • Relative humidity sensor (internal)
  • Barometer (internal)
  • Accelerometer

MORE DETAILS

Sensors and interfaces

  • WISE RF communication
  • Internal antenna
  • UPS power supply backup (mains versions)
  • Internal thermometer
  • Ruggedized IP-67 enclosure
  • Sensor supply voltage generation
  • M8-style sensor connectors

Avic Legiobox

BasicGate

Avic Legiobox

BasicGate

The LegioBox BasicGate is Avic’s all-round IoT device for stand-alone operation in industrial environments. It can be powered either from universal AC mains or 24 VDC, supported by an internal back-up battery. The LegioBox BasicGate can either connect to a local area network (Ethernet), or through cellular networks using its 2G/3G or LTE modem. The LegioBox BasiGate supports a multitude of industry-standard process interfaces, as well as data communication ports.

The LegioBox BasicGate allows any of its six analog sensor interfaces to be configured as 4-20mA current, Pt-1000 thermometer, or 0-10VDC voltage sensor. In addition, the LegioBox BasicGate provides four digital inputs, as well as 8 user-definable LED indicators. Sensors and other peripherals can be connected to the LegioBox BasicGate in any arrangement.

Protected by a robust die-cast aluminum enclosure, the LegioBox BasicGate is designed to work in heavy-duty industrial environments. Mounting accesories are available to ensure that the LegioBox BasicGate is securely installed during operation.

Product features

  • Cellular, LAN or WiFi communication interface
  • Holder for replaceable SIM card
  • UPS power supply backup
  • SD card storage memory
  • Robust, metal IP-67 enclosure
  • Sensor supply voltage generation
  • High-precision 24-bit analog-to-digital conversion
  • Push-in terminal connectors

Sensors and interfaces

  • Pt-1000 temperature sensor interfaces
  • 4-20mA sensor intrerfaces
  • 0-10VDC sensor interfaces
  • Digital inputs
  • RS-232 data communication port
  • RS-485 data communication port
  • Wide-input AC or 24VDC supply voltage

MORE DETAILS

The LegioBox BasicGate is Avic’s all-round IoT device for stand-alone operation in industrial environments. It can be powered either from universal AC mains or 24 VDC, supported by an internal back-up battery. The LegioBox BasicGate can either connect to a local area network (Ethernet), or through cellular networks using its 2G/3G or LTE modem. The LegioBox BasiGate supports a multitude of industry-standard process interfaces, as well as data communication ports.

The LegioBox BasicGate allows any of its six analog sensor interfaces to be configured as 4-20mA current, Pt-1000 thermometer, or 0-10VDC voltage sensor. In addition, the LegioBox BasicGate provides four digital inputs, as well as 8 user-definable LED indicators. Sensors and other peripherals can be connected to the LegioBox BasicGate in any arrangement.

Protected by a robust die-cast aluminum enclosure, the LegioBox BasicGate is designed to work in heavy-duty industrial environments. Mounting accesories are available to ensure that the LegioBox BasicGate is securely installed during operation.

Product features

  • Cellular, LAN or WiFi communication interface
  • Holder for replaceable SIM card
  • UPS power supply backup
  • SD card storage memory
  • Robust, metal IP-67 enclosure
  • Sensor supply voltage generation
  • High-precision 24-bit analog-to-digital conversion
  • Push-in terminal connectors

MORE DETAILS

Sensors and interfaces

  • Pt-1000 temperature sensor interfaces
  • 4-20mA sensor intrerfaces
  • 0-10VDC sensor interfaces
  • Digital inputs
  • RS-232 data communication port
  • RS-485 data communication port
  • Wide-input AC or 24VDC supply voltage

Avic Legiobox

SolarGate

Avic Legiobox

SolarGate

The LegioBox SolarGate is Avic’s solar-powered IoT device, targeted at solutions that need to operate independently of, or supported by external power supplies. When the ambient light is sufficient, the integrated photovoltaic panel charges the LegioBox SolarGate internal battery that ensures uninterrupted operation. Various cellular interfaces are available to meet the application communication bandwidth requirements.

Many different sensor types in varying combinations can be connected to the LegioBox SolarGate, as well as digital inputs and serial interfaces. The LegioBox SolarGate runs entirely stand-alone from its integrated power sources, and also generates all sensor supply voltages. Using Avic’s WISE wireless networking protocol, additional sensor nodes such as the LegioBox PicoWise can be connected.

The LegioBox SolarGate works reliably under harsh and ever-changing weather conditions, protected by its ruggedized and UV-resistant enclosure. Mounting accesories are available to ensure that the LegioBox SolarGate is securely installed during operation.

Product features

  • Push-in terminal connectors
  • Cat-M1/NB-IoT cellular interface with 2G-fallback
  • WISE wireless networking
  • GNSS geo-localization
  • Integrated solar panel
  • Solar-charged battery
  • SD card storage memory
  • Ruggedized IP-66 enclosure
  • Sensor supply voltage generation
  • High-precision 24-bit analog-to-digital conversion
  • Push-in terminal connectors

Sensors and interfaces

  •  Pt-1000 temperature sensor interface
  • 4-20mA sensor intrerfaces
  • 0-10VDC sensor interface
  • Digital inputs
  • RS-232 data communication port
  • RS-485 data communication port
  • SDI-12 conmmunication port
  • Internal barometer and thermometer
  • Internal elative humidity sensor
  • Internal accelerometer

MORE DETAILS

The LegioBox SolarGate is Avic’s solar-powered IoT device, targeted at solutions that need to operate independently of, or supported by external power supplies. When the ambient light is sufficient, the integrated photovoltaic panel charges the LegioBox SolarGate internal battery that ensures uninterrupted operation. Various cellular interfaces are available to meet the application communication bandwidth requirements.

Many different sensor types in varying combinations can be connected to the LegioBox SolarGate, as well as digital inputs and serial interfaces. The LegioBox SolarGate runs entirely stand-alone from its integrated power sources, and also generates all sensor supply voltages. Using Avic’s WISE wireless networking protocol, additional sensor nodes such as the LegioBox PicoWise can be connected.

The LegioBox SolarGate works reliably under harsh and ever-changing weather conditions, protected by its ruggedized and UV-resistant enclosure. Mounting accesories are available to ensure that the LegioBox SolarGate is securely installed during operation.

Product features

  • Push-in terminal connectors
  • Cat-M1/NB-IoT cellular interface with 2G-fallback
  • WISE wireless networking
  • GNSS geo-localization
  • Integrated solar panel
  • Solar-charged battery
  • SD card storage memory
  • Ruggedized IP-66 enclosure
  • Sensor supply voltage generation
  • High-precision 24-bit analog-to-digital conversion
  • Push-in terminal connectors

MORE DETAILS

Sensors and interfaces

  •  Pt-1000 temperature sensor interface
  • 4-20mA sensor intrerfaces
  • 0-10VDC sensor interface
  • Digital inputs
  • RS-232 data communication port
  • RS-485 data communication port
  • SDI-12 conmmunication port
  • Internal barometer and thermometer
  • Internal elative humidity sensor
  • Internal accelerometer

Avic Legiobox

NanoGate

Avic Legiobox

NanoGate

The LegioBox NanoGate is a compact and highly energy-efficient, yet powerful IoT device with a comprehensive set of application interfaces. The clever LegioBox NanoGate product architecture allows almost any configuration of interfaces to compose the functionality for your IoT solution. Internally, the LegioBox NanoGate offers a number of integrated sensors to even further enhance your application.

For local and remote communication, the LegioBox NanoGate provides a number of wired and wireless data communication interfaces. Thus, the LegioBox NanoGate can serve as a wireless hub for sensors, or as a gateway for a wireless sensor network. The versatility of the LegioBox NanoGate makes it a perfect fit for almost any IoT project.

The LegioBox NanoGate is designed to withstand even the harshest conditions, protected by its ruggedized enclosure, and high-quality weatherproof connectors. Mounting accesories are available to ensure that the LegioBox NanoGate is always securely installed during operation. Its power management architecture selectively activates the functionality only when it’s needed, minimizing energy consumption and conserving battery life.

Product features

  • Cat-M1/NB-IoT cellular interface with 2G-fallback
  • Ethernet and wireless LAN interface
  • WISE wireless networking
  • Internal antennas
  • SD card storage memory
  • Ruggedized IP-67 enclosure
  • Sensor supply voltage generation
  • High-precision 24-bit analog-to-digital conversion
  • UPS power supply backup (mains versions)
  • M12-style sensor connectors

Sensors and interfaces

  • Pt-1000 temperature sensor interface
  • 4-20mA sensor intrerfaces
  • 0-10VDC sensor interface
  • Digital inputs
  • RS-232 data communication port
  • RS-485 data communication port
  • SDI-12 conmmunication port
  • Internal barometer and thermometer
  • Internal elative humidity sensor
  • Internal accelerometer

MORE DETAILS

The LegioBox NanoGate is a compact and highly energy-efficient, yet powerful IoT device with a comprehensive set of application interfaces. The clever LegioBox NanoGate product architecture allows almost any configuration of interfaces to compose the functionality for your IoT solution. Internally, the LegioBox NanoGate offers a number of integrated sensors to even further enhance your application.

For local and remote communication, the LegioBox NanoGate provides a number of wired and wireless data communication interfaces. Thus, the LegioBox NanoGate can serve as a wireless hub for sensors, or as a gateway for a wireless sensor network. The versatility of the LegioBox NanoGate makes it a perfect fit for almost any IoT project.

The LegioBox NanoGate is designed to withstand even the harshest conditions, protected by its ruggedized enclosure, and high-quality weatherproof connectors. Mounting accesories are available to ensure that the LegioBox NanoGate is always securely installed during operation. Its power management architecture selectively activates the functionality only when it’s needed, minimizing energy consumption and conserving battery life.

Product features

  • Cat-M1/NB-IoT cellular interface with 2G-fallback
  • Ethernet and wireless LAN interface
  • WISE wireless networking
  • Internal antennas
  • SD card storage memory
  • Ruggedized IP-67 enclosure
  • Sensor supply voltage generation
  • High-precision 24-bit analog-to-digital conversion
  • UPS power supply backup (mains versions)
  • M12-style sensor connectors

MORE DETAILS

Sensors and interfaces

  • Pt-1000 temperature sensor interface
  • 4-20mA sensor intrerfaces
  • 0-10VDC sensor interface
  • Digital inputs
  • RS-232 data communication port
  • RS-485 data communication port
  • SDI-12 conmmunication port
  • Internal barometer and thermometer
  • Internal elative humidity sensor
  • Internal accelerometer

Avic Legiobox

MiniGate

Avic Legiobox

MiniGate

The LegioBox MiniGate is Avic’s most compact IoT device, designed for space-constrained applications that require only a few sensor values. Equipped with either a GRPS or NB-IoT cellular modem, the MiniGate performs its measurements indepedently of local communication infrastructure. For local interfacing to peripheral devices through serial links, the MiniGate features a RS-232, RS-485, or SDI-12 data communication port.

Various analog and digital sensors can be connected to the LegioBox MiniGate, that – thanks to the integrated sensor supply voltage generation – do not require additional power sources for performing measurements. The LegioBox MiniGate also provides digital inputs, a relay output and integrated environmental sensors.

The LegioBox MiniGate is designed to work in any-weather outdoor applications. The operation of the LegioBox MiniGate analog and digital interfaces can easily be tailored to the application with jumper settings. Mounting accesories are available to ensure that the LegioBox MiniGate is securely installed during operation.

Product features

  • Cat-M1/NB-IoT cellular interface with 2G-fallback
  • GNSS geo-localization
  • Internal antennas
  • Battery-powered
  • SD card storage memory
  • Ruggedized IP-67 enclosure
  • Sensor supply voltage generation
  • High-precision 24-bit analog-to-digital conversion
  • Push-in terminal connectors
  • Cable gland entry

Sensors and interfaces

  • Pt-1000 temperature sensor interface
  • 4-20mA sensor intrerfaces
  • 0-10VDC sensor interface
  • Digital inputs (2) and relay output
  • RS-232 data communication port
  • RS-485 data communication port
  • SDI-12 conmmunication port
  • Internal barometer and thermometer
  • Internal relative humidity sensor
  • Internal accelerometer

MORE DETAILS

The LegioBox MiniGate is Avic’s most compact IoT device, designed for space-constrained applications that require only a few sensor values. Equipped with either a GRPS or NB-IoT cellular modem, the MiniGate performs its measurements indepedently of local communication infrastructure. For local interfacing to peripheral devices through serial links, the MiniGate features a RS-232, RS-485, or SDI-12 data communication port.

Various analog and digital sensors can be connected to the LegioBox MiniGate, that – thanks to the integrated sensor supply voltage generation – do not require additional power sources for performing measurements. The LegioBox MiniGate also provides digital inputs, a relay output and integrated environmental sensors.

The LegioBox MiniGate is designed to work in any-weather outdoor applications. The operation of the LegioBox MiniGate analog and digital interfaces can easily be tailored to the application with jumper settings. Mounting accesories are available to ensure that the LegioBox MiniGate is securely installed during operation.

Product features

  • Cat-M1/NB-IoT cellular interface with 2G-fallback
  • GNSS geo-localization
  • Internal antennas
  • Battery-powered
  • SD card storage memory
  • Ruggedized IP-67 enclosure
  • Sensor supply voltage generation
  • High-precision 24-bit analog-to-digital conversion
  • Push-in terminal connectors
  • Cable gland entry

MORE DETAILS

Sensors and interfaces

  • Pt-1000 temperature sensor interface
  • 4-20mA sensor intrerfaces
  • 0-10VDC sensor interface
  • Digital inputs (2) and relay output
  • RS-232 data communication port
  • RS-485 data communication port
  • SDI-12 conmmunication port
  • Internal barometer and thermometer
  • Internal relative humidity sensor
  • Internal accelerometer

Avic Legiobox

LightGate

Avic Legiobox

LightGate

The LegioBox LightGate IoT device is unique in its kind: shaped as signal lamp, it conceals a rich set of features. Operating from 24VDC or 24VAC supply voltages, with a back-up battery to cope with power outages, it connects analog sensors, digital inputs, and serial interfaces. And of course, it also illuminates LEDs at varying patterns to signal the detection of user-definable conditions.

The LegioBox LightGate provides interfaces for 4-20mA current, Pt-1000 thermometer, or 0-10VDC voltage analog sensors. The sensor supply voltages are generated by the LegioBox LightGate, making external powering of sensors unnecessary. In addition, the LegioBox LightGate provides three digital inputs, as well as a relay for control purposes. Furthermore, the LegioBox LightGate offers a number of integrated environmental sensors.

The LegioBox LightGate is well suited to work in any-weather outdoor applications. Its clever housing design makes installation, e.g. onto cabinet enclosures, by simply tightening a single mounting screw, very straightforward.

Product features

  • Cat-M1/NB-IoT cellular interface with 2G-fallback
  • Internal antenna
  • UPS power supply backup
  • Sensor supply voltage generation
  • LED signal function
  • GNSS geo-localization
  • Ruggedized IP-67 enclosure
  • Digital inputs
  • Control relay

Sensors and interfaces

  • Pt-1000 temperature sensor interfaces
  • 4-20mA sensor intrerfaces
  • 0-10VDC sensor interfaces
  • RS-232 data communication port
  • RS-485 data communication port
  • Temperature sensor (internal)
  • Relative humidity sensor (internal)
  • Barometer (internal)
  • Accelerometer (internal)

MORE DETAILS

The LegioBox LightGate IoT device is unique in its kind: shaped as signal lamp, it conceals a rich set of features. Operating from 24VDC or 24VAC supply voltages, with a back-up battery to cope with power outages, it connects analog sensors, digital inputs, and serial interfaces. And of course, it also illuminates LEDs at varying patterns to signal the detection of user-definable conditions.

The LegioBox LightGate provides interfaces for 4-20mA current, Pt-1000 thermometer, or 0-10VDC voltage analog sensors. The sensor supply voltages are generated by the LegioBox LightGate, making external powering of sensors unnecessary. In addition, the LegioBox LightGate provides three digital inputs, as well as a relay for control purposes. Furthermore, the LegioBox LightGate offers a number of integrated environmental sensors.

The LegioBox LightGate is well suited to work in any-weather outdoor applications. Its clever housing design makes installation, e.g. onto cabinet enclosures, by simply tightening a single mounting screw, very straightforward.

Product features

  • Cat-M1/NB-IoT cellular interface with 2G-fallback
  • Internal antenna
  • UPS power supply backup
  • Sensor supply voltage generation
  • LED signal function
  • GNSS geo-localization
  • Ruggedized IP-67 enclosure
  • Digital inputs
  • Control relay

MORE DETAILS

Sensors and interfaces

  • Pt-1000 temperature sensor interfaces
  • 4-20mA sensor intrerfaces
  • 0-10VDC sensor interfaces
  • RS-232 data communication port
  • RS-485 data communication port
  • Temperature sensor (internal)
  • Relative humidity sensor (internal)
  • Barometer (internal)
  • Accelerometer (internal)

With more than 20 years of IoT experience and serving almost every industry with our hard and software we love to help you as well!
Call us for a free trial or demonstration.

find us on

Download our Privacy statement

Address

Molenwal 20a
5301 AW Zaltbommel
Nederland

T. +31 (0) 418674700
F. +31 (0) 418674111

info@avic.nl

With more than 20 years of IoT experience and serving almost every industry with our hard and software we love to help you as well!
Call us for a free trial or demonstration.

find us on

Download our Privacy statement

Address

Molenwal 20a
5301 AW Zaltbommel| Nederland

T. +31 (0) 418674700 | F. +31 (0) 418674111

info@avic.nl

Copyright 2020  |  Avic BV Zaltbommel

Pop Up WordPress Plugin
AVIC
